Announcing the **NEW** Thunder Bolt Plus!**NEW** The Bolt Pro 32 series laser engraver and cutting machinecombines a compact size, with high-quality engraving and cutting at alow cost.
With 1GB memory and a high-resolution camera, the Bolt Pro 32 isperfect for ultra-refined detailing.
With rotary capabilities for curved engravings, With 5G acceleration and80 IPS (2000mm/sec) engraving speed, it provides a fast laser engravingsolution for industry
Excellent quality beam output and stable laser power. Lifespan up to 10,000 hours.
Real-time camera preview, clear imagery, precise positioning of designs.
Low vibration and low noise stepper running 1000mm/s. Achieve a 3x increase in engraving speed
Quickly control your machine and access the most frequently used functions through the shortcut button on the main screen
No limitation on materials or working area. The auto focus feature also been improved for accuracy.
Allowing you to store up to 100 project files, you can also work independently away from the computer.
Air Assist
Exhaust
Pilot Lamp
Rail
Honeycomb
Fire Alarm
Touch Screen Panel
Emergency Stop
Tool Kit for Bolt Pro 22
| Bolt Pro 32
Tool Bag for Bolt | Bolt
Plus
| Specifications | Bolt | ||
|---|---|---|---|
| Machine Size | 941*724*498mm (37.0″ x 28.5″x 19.6″) | ||
| Working Area | 508*305mm (20″ × 12″) | ||
| Working Table | 510*310mm （20.1″ x 12.1″） | ||
| Maximum Lifting | 113mm / 4.45″ | ||
| Z Axis Height | 110mm / 4.33″ | ||
| Max Part Size | 508*305mm (20.0″ x 12.0″) | ||
| Max Load | 10kg / 22.05 lbs | ||
| Machine Weight | 77kg / 169.76 lbs | ||
| Repeat positioning accuracy | 0.01mm | ||
| Max. scanning speed | 1,500mm/s | ||
| Max. cutting speed | 300mm/s | ||
| Acceleration | 3G, 30,000mm/s² | ||
| Rotary Diameter | 0~90mm | ||
| Laser Type | Standard: 30W SPT RF Tube Optional: 60W SPT / 30W Coherent RF Tube | ||
| Working Platform | Honeycomb Table | ||
| Laser head | Standard: 2.5″ Optional: 1.5″, 2.0″, 4.0″ | ||
| Pass-through Door | Front Pass-through Door | ||
| Rotary | Accessible | ||
| Laser head lifetime / hour | 10,000+ | ||
| Voltage | 230V±5% or 110V±10% | ||
| Focus Lens | 1*20mm 2.5″CO2 Focus Lens | ||
| Reflector | 3*25mm CO2 Silicon Reflector | ||
| Beam Combiner | 1*25mm CO2 Beam Combiner | ||
| Window Mirror | / | ||
| Expander | 1*3x Divergence Angle-Adjustable CO2 Expander | ||
| Cooling System | Air Cooling | ||
| Air assist system | Dual-channel air assist with integrated digital flow meter | ||
| Nozzle | 3mm | ||
| Connections | Ethernet, USB Cable, USB Disk | ||
| Memory | 1GB (1024MB) | ||
| Software | LaserMaker, LightBurn, RDWorks Supported | ||
| Camera | 5MP Mounted Camera | ||
| Safety | FDA Class2, CE | ||
| Warranty | 2 Years Warranty |
| Specifications | Bolt Plus | ||
|---|---|---|---|
| Laser Source | 30 W Coherent RF (comparable to a 70W glass tube) | ||
| Working Area | 20″ x 12″ | ||
| Max Material Height | 4.3″(up to 12″ if honeycomb is removed) | ||
| Cutting Abilities | 3/8″ MDF and 1/2″ Acrylic | ||
| Machine Dimensions | 37″ x 28.5″ x 19.6″ / 77kg / 170lbs | ||
| Cooling | Air Cooled | ||
| Acceleration Speed | 5G | ||
| Air Assist | Dual | ||
| Engraving Speed | 1500 mm/s | ||
| Max Resolution | 2,000 DPI with 1.5″ Lens | ||
| Computer Connection | Ethernet or USB Connection | ||
| Rotary Compatible | Yes(Thunder Chuck or PiBurn) | ||
| Cutting | Wood, MDF, Acrylic, Leather, Fabric, Rubber and more! | ||
| Engraving | Wood, MDF, Acrylic, Leather, Glass, Coated Tumblers, Rubber, Plastics, Anodized Aluminum and more! | ||
| Standard Lens | 2.5″ | ||
| Auto Focus | Yes | ||
| Built – In Camera | Yes | ||
| Support | Free Canada based lifetime support | ||
| Software | RDWorks included(LightBurn available for purchase) |
| Specifications | Bolt Pro 22 | ||
|---|---|---|---|
| Laser Source | 30 W Coherent RF (comparable to a 70W glass tube) | ||
| Working Area | 22″ x 15″ | ||
| Max Material Height | 7.3″ | ||
| Cutting Abilities | 3/8″ MDF and 1/2″ Acrylic | ||
| Machine Dimensions | 40″ x 34″ x 43″ 125kgs (275lbs) | ||
| Cooling | Air Cooled | ||
| Acceleration Speed | 5G | ||
| Air Assist | Dual | ||
| Engraving Speed | 2000 mm/s | ||
| Max Resolution | 2,000 DPI with 1.5″ Lens | ||
| Computer Connection | Ethernet or USB Connection | ||
| Rotary Compatible | Yes(Thunder Chuck or PiBurn) | ||
| Cutting | Wood, MDF, Acrylic, Leather, Fabric, Rubber and more! | ||
| Engraving | Wood, MDF, Acrylic, Leather, Glass, Coated Tumblers, Rubber, Plastics, Anodized Aluminum and more! | ||
| Standard Lens | 2.5″ | ||
| Auto Focus | Yes | ||
| Built – In Camera | Yes | ||
| Support | Free Canada based lifetime support | ||
| Software | RDWorks included(LightBurn available for purchase) |
| Specifications | Bolt Pro 32 | ||
|---|---|---|---|
| Laser Source | 55 W Coherent RF (comparable to a 100W glass tube) | ||
| Working Area | 32″ x 20″ | ||
| Max Material Height | 7.3″ | ||
| Cutting Abilities | 1/2″ MDF and 3/4″ Acrylic | ||
| Machine Dimensions | 51″ x 39″ x 43″ 300kgs (661lbs) | ||
| Cooling | Air Cooled | ||
| Acceleration Speed | 5G | ||
| Air Assist | Dual | ||
| Engraving Speed | 2000 mm/s | ||
| Max Resolution | 2,000 DPI with 1.5″ Lens | ||
| Computer Connection | Ethernet or USB Connection | ||
| Rotary Compatible | Yes(Thunder Chuck or PiBurn) | ||
| Cutting | Wood, MDF, Acrylic, Leather, Fabric, Rubber and more! | ||
| Engraving | Wood, MDF, Acrylic, Leather, Glass, Coated Tumblers, Rubber, Plastics, Anodized Aluminum and more! | ||
| Standard Lens | 2.5″ | ||
| Auto Focus | Yes | ||
| Built – In Camera | Yes | ||
| Support | Free Canada based lifetime support | ||
| Software | RDWorks included(LightBurn available for purchase) |
| Specifications | Thunder Bolt | ||
|---|---|---|---|
| Laser Source | CO2 RF laser 30w | ||
| Dimensions | 37″ x 28.5″ x 19.6″ / 941 x 724 x 498mm | ||
| Working area | 20″ x 12″ / 508 x 305mm | ||
| Max speed | 1000mm/s | ||
| Z axis Height | 4.3″ / 110mm | ||
| Cooling | Air | ||
| Autofocus | Yes | ||
| Touch screen controls | Yes | ||
| Rotary | Yes | ||
| Software | RDWorks included, LightBurn Software available for purchase | ||
| Weight | 77kg / 170lbs | ||
| Engraving Resolution | 2,000 DPI | ||
| Exhaust tube size | 100mm |
We offer a 2-year factory warranty on our machines.
As long as you know how to design jobs in graphic software, it just takes a few hours for you to become a master of laser machine. You just need to do some tests to know what speed and power is good for different materials. Since we’ve provided some of the parameter library, it will save you more time.You can watch the guiding videos from our website to learn how to use the machine in advance too.
https://www.thunderlaser.com/video/what-laser-cutter-can-create.html
https://www.thunderlaser.com/video/how-to-use-your-laser-machine.html
https://www.thunderlaser.com/video/how-to-use-your-laser-software.html
Install a removable rotary attachment in your laser engraving machine for cylindrical glass, wood, or metal products.
Install a removable rotary attachment in your laser engraving machine for cylindrical glass, wood, or metal products.
Lenses available for all project types. The more detailed the graphics, the shorter the focal length.
The thicker the material, the greater the focal length is required.
